90° Standard Glass-to-Glass Hinge
Model: G204
Product Details
Product Overview
- Available in Several Elegant Finishes
- Three-Year Warranty
- 90-Degree Glass-to-Glass
The FMF professional hinges are compatible with 3/8" (10 mm) to 1/2" (12 mm) tempered glass. These hinges are crafted from solid brass, with all moving components, such as pins and springs, made from stainless steel for lasting durability.
Strength and Durability:
- With two hinges, the Hinge can support doors up to 80 lbs. (36 kg) with a maximum door width of 28" (711 mm).
- With three hinges, the hinge can support doors up to 120 lbs. (54 kg) with a maximum door width of 32" (813 mm).
Specifications:
- Glass Thickness: 5/16" (8 mm) to 1/2" (12 mm) tempered safety glass
- Special Feature: Choose between the Standard Model, which is factory-set to a 0-degree closing position, or the 5-degree Pre-Set Model for a tighter closure into the shower interior.
- Construction: Solid brass
- Hinge Swings: 90 degrees in and 90 degrees out
- Closing Type: Self-centering when within 15 degrees of the closed position
Cut-Out Required
Includes: Gaskets, screws, and glass fabrication dimensions.
We manufacture them in Solid Brass to provide durability and rust resistance, allowing them to function for several years. Our beautiful finishes for the hinges are sure to transform the bathroom space by providing an all-glass look to the shower enclosures.
