Top L-Crank Patch Fitting

Model: PAT-04

L-Shape Patch Fitting Top-Crank
Secure Over Panel & Side Panel
For Interior Use Only
Door Swings Both Ways

Applicable For: 10-12MM Tempered Glass
Construction Material: Aluminum Body With 304 Grade Stainless Steel Cover Plate
Shipping Weight: 1 LBS (454 Grams Approx.)
Compatible With: FMF Patch Hardware
Cut Out Required: Please Refer To Attached Cut Out Diagram Above
Function: Connects Transom
Accessories: Screws, Gaskets, Fabrication Diagram
Warranty: Limited 1 Year Warranty
Ship Via: Third party courier service

Quantity
-
1
+







For Interior Use Only

Applicable For: 10-12MM Tempered Glass
Construction Material: Aluminium Body With 304 Grade Stainless Steel Cover Plate
Shipping Weight: 1 LBS (454 Grams Approx.)
Compatible With: HYP100, HYP120 & HYP150
Cut Out Required: Please Refer To Attached Cut Out Diagram Above
Function: Connects Side Panel To Top Transom Panel, Swings 90° In + 90° Out
Accessories: Screws, Gaskets, Fabrication Diagram
Warranty: Limited 1 Year Warranty
Ship Via: Third-party courier service

Our Top L-Crank Patch Fittings are durable and easy to use. They are widely appreciated for their faultless performance by our clients. They are designed to fix over panel and side panels. Suitable for interior applications, these fittings enable the movement of the door in both directions.

Made of aluminum body, the fittings are sturdy to retain their original shape and resist rust. They can keep a smooth surface for a long time. They connect transoms effortlessly and complement the overall theme of the area with three attractive finishes.
