4" Commercial Top Door Rail
Model:
TOP-DR0136.BN

4" Commercial Top Door Rail

36β€³ Top Door Rail System-BN
FinishBrushed Nickel
Size
PICKUP LOCATION IN STOCK
FMF Hardware Supply | Concord …
FMF Glass Hardware | Mississauga …
FMF Hardware Solutions | Woodbridge Out of stock
Product Details βˆ’
Dimensions: Length: 41 in , Width: 4.5 in , Height: 7.5 in Finish/Color: Brushed Nickel
Applicable: 10-12MM Tempered Glass Shipping Weight: 21
Material: Aluminum Body With 316 Grade Stainless Steel Cover Plate Warranty: Limited 1-year warranty
Shipping Method: Via third-party courier service
Product Overview +

The FMF Commercial Top Glass Door Rail Profile offers a strong, durable, and compact solution for frameless glass door installations. Designed with a lock-free profile, this rail provides a clean, modern aesthetic while ensuring strength and long-lasting reliability. Perfect for commercial, residential, and hospitality applications, this top rail complements frameless glass doors, partitions, and railings.

Key Features:

  • Durable Construction: Made from 6060 T6 aluminum for superior strength and corrosion resistance.
  • Clean Aesthetic: Lock-free design for a modern, frameless look.
  • Easy Installation: Requires no special tools for installation.
  • Glass Compatibility: Fits 10mm–12mm tempered glass.

Technical Specification:

  • Material: 6060 T6 Aluminum
  • Dimensions (L Γ— H Γ— W) HYP-R10036: 35 15/16β€³ (L) Γ— 4 1/4β€³ (H) Γ— 2 1/16β€³ (W).
  • Dimensions (L Γ— H Γ— W) HYP-R10038: 37 3/4β€³ (L) Γ— 4 1/2β€³ (H) Γ— 2 1/16β€³ (W)
  • Glass Thickness: 10mm – 12mm Tempered Glass
  • Lock Option: Optional
  • Load Capacity: Up to 100 kg (500,000 Cycle Tests)
  • Packaging Dimensions HYP-R10036: 41β€³ (L) Γ— 4 1/2β€³ (H) Γ— 7 1/2β€³ (W)
  • Packaging Dimensions HYP-R10038: 44β€³ (L) Γ— 5β€³ (H) Γ— 8β€³ (W)
  • Gross Weight HYP-R10036: 17 lb
  • Gross Weight HYP-R10038: 21 lb
  • Finish Options: Matte Black, Brushed Nickel

Installation Instructions:

  • Preparation: Ensure all surfaces are clean and level before installation.
  • Measurement: Mark the positions for the rail based on door width and height.
  • Drilling: Drill holes for rail mounting (no special tools required).
  • Placement: Position the rail and align it with the glass door.
  • Securing: Attach the rail securely and ensure the glass door is stable.
  • Final Inspection: Check for proper alignment and smooth operation of the door.

Maintenance & Care:

  • Clean regularly with a soft cloth and mild cleaning solution to maintain finish and appearance.
  • Avoid using abrasive materials that may damage the surface.
  • Periodically check that mounting screws are tightened and the rail is securely fixed.

Date of Release:

February 11 2025

Warranty Period:

1 Year Limited Waranty
