52mm Zinc Square Glass Railing Clamp – Flat Base (Interior) – Matte Black

52mm Zinc Square Glass Railing Clamp – Flat Base (Interior)

Matte Black
Skip to product information
52mm Zinc Square Glass Railing Clamp – Flat Base (Interior) – Matte Black
Model:
RCS-06.BL

52mm Zinc Square Glass Railing Clamp – Flat Base (Interior)

FinishMatte Black
PICKUP LOCATION IN STOCK
FMF Hardware Supply | Concord …
FMF Glass Hardware | Mississauga …
FMF Hardware Solutions | Woodbridge …
Product Details −
Shipping Dimensions: Length: 2 in , Width: 2 in , Height: 2 in Finish/Color: Matte Black
Applicable: 10-12MM Tempered Glass Shipping Weight: 0.1
Material: Zinc Alloy Warranty: Limited 1-year warranty
Shipping Method: Via third-party courier service
Product Overview +

52mm Zinc Square Glass Railing Clamp – Flat Base (Interior)
Model: RCS-06

The FMF 52 mm Zinc Square Glass Railing Clamp with Flat Base holds frameless glass railing panels securely to a flat surface. Its 52 × 52 mm square body and flat back mount directly to square posts, walls and other flat surfaces, giving a clean, modern look on interior railings, partitions and mezzanines.

Made from zinc alloy, it is a cost-effective clamp for interior railings and partitions. The clamp fits 10 mm (3/8") and 12 mm (1/2") tempered glass, with rubber gaskets included, and an optional safety pin adds extra hold.

Key Features

  • Flat Base Design: Flat back mounts directly to square posts, walls and other flat surfaces.
  • 52 mm Square Body: 52 × 52 mm square profile for a strong, clean look.
  • Zinc Alloy Construction: Durable, cost-effective zinc alloy for indoor use.
  • Fits 10–12 mm Glass: Rubber gaskets for 10 mm and 12 mm tempered glass are included.
  • Adjustable Fit: Repositionable glass holding plate helps line up the glass during installation.
  • Optional Safety Pin: Use with a pin hole in the glass for extra security in high-traffic areas.
  • Interior Use Only: Zinc alloy is for indoor railings, partitions and mezzanines; choose a stainless clamp for outdoor use.
  • Finish Options: Brushed Stainless or Matte Black.

Specifications

  • Product Type: Zinc square glass railing clamp, flat base
  • Model: RCS-06
  • Material: Zinc alloy
  • Size: 52 × 52 × 32 mm
  • Mounting: Flat base, for square posts, walls and other flat surfaces
  • Glass: 10 mm (3/8") or 12 mm (1/2") tempered
  • Glass Cut-Out: Optional hole for the safety pin; see the glass fabrication drawing
  • Shipping Weight: Approx. 1 lb (450 g)
  • Application: Interior glass railings, partitions and mezzanines
  • Use: Residential and commercial, interior only
  • Warranty: Limited 1-year warranty

Available Finishes

  • Brushed Stainless
  • Matte Black

Kit Contents

  • 1 × 52 mm zinc square glass railing clamp, flat base
  • Mounting screws
  • Rubber gaskets for 10 mm and 12 mm glass

Installation & Support

  • Ease of Installation: Screw the base to the post or wall, fit the gasket for your glass thickness, then set and tighten the glass.
  • Glass Fabrication: No cut-out is needed unless you use the optional safety pin; see the glass fabrication drawing.
  • Application: Interior glass railings, stair railings, partitions and mezzanines.
  • Compatible Accessories: FMF square railing post kits and 10–12 mm tempered glass panels, sold separately.
  • Warranty: Backed by FMF’s limited 1-year warranty.
  • Shipping: Ships via third-party courier service.
